2013–2014 Chevrolet Orlando 1.4 Turbo Specs &amp; Performance

Tech Specs Summary

MSRP:$7,000 – $10,000

Power: 138 hp
0-60 mph: 10.6s
Top Speed: 124 mph
Economy: 36.7 mpg
Drivetrain: FWD
Seats: 7
Doors: 5
Luggage: 3.6–56.3 ft³
Weight: 3,558 lbs

1 / 6

Performance & Efficiency

Speed & Power

Top Speed: 124 mph
Power: 138 hp
Torque: 148 lb-ft
0-60 mph: 10.6s
0-62 mph: 11.0 seconds
Power-to-Weight: 25.79 lb/hp

Efficiency & Range

Combined: 36.7 mpg
Total Range: 582 Miles
Tailpipe CO₂: 240 g/Mile

Engine & Powertrain

Gasoline Engine

Capacity: 1.4 Liter
Layout: Inline 4
Aspiration: Turbo
Peak Power: 138 hp @ 4,900 RPM
Peak Torque: 148 lb-ft @ 1,850 RPM
Valvetrain: DOHC
Valves/Cylinder: 4 (16v Total)
Fuel Injection: Multi-point
Fuel: Gasoline
Position: Front Engine
Orientation: Transversal
Fuel Tank Capacity: 15.9 Gallons

Engine Details

Specific Output: 1.66 hp/in³
Power/Cylinder: 35 hp
Cylinder Volume: 20.8 in³
Bore x Stroke: 2.854 x 3.248 in
Bore-Stroke Ratio: 0.88:1
Compression Ratio: 9.5:1
BMEP: 267.6 PSI

Drivetrain & Chassis

Drivetrain

Driven Wheels: FWD = Front-Wheel Drive
Transmission (MT): 6 Speeds

Suspension, Brakes & Tyres

Front Suspension: MacPherson Strut
Rear Suspension: Torsion Beam
Front Brakes: Vented Disc
Rear Brakes: Solid Disc
Tyre Sizes: 215/60R16 V

Dimensions & Practicality

Outline is illustrative, not to scale.

Size

Length: 183.1 in
Width: 72.3 in
Height: 64.3 in
Wheelbase: 108.7 in
Front Track: 62.4 in
Rear Track: 62.5 in

Capacity & Seating

Body: Medium MPV
Door Count: 5
Seat Count: 7
Luggage Space: 3.6–56.3 ft³

Weight & Towing

Curb Weight: 3,558 lbs
Gross Weight: 4,804 lbs
Maximum Payload: 1,246 lbs
Towing Capacity: 2,425 lbs
